Part Story

Dsp End Yokes

Part Number 3504-101

  • Series: 1350
  • Spline Count: 10
  • Spline Diameter: 1.375
  • Hub Diameter: 1.750
  • Thru Hole: 1.500
  • Centerline To End: 3.188
  • Style: UB
  • Vehicle Class: LD
  • Brand: PTI
Part Story

This 1350 end yoke is the same as the Spicer 3-4-178-1X. Powertrain use to use this yoke to build 1350 Limo shafts.

Powertrain, for the most part, is now using the 3504-29 (29 spline) instead of the 3504-101 (10 spline) for limo shafts.

This yoke takes the Spicer u-bolt kit number 3-94-18X.
