Part Story

Dsp Flange Yokes

Part Number 3502-0144

  • Series: 1350
  • Pilot Type: F
  • Pilot Diameter: 0.551
  • Bolt Circle Diameter: 3.780
  • Bolt Hole Count: 3
  • Bolt Hole Diameter: 0.480
  • Centerline To Face: 3.000
  • Swing Diameter: 5.450
  • Notes: Aluminum 6061-T6 Tri Flange, 96mm (3.780) bolt circle, Hole to hole 3.273", 14mm nose hole, 12mm bolt holes
  • Vehicle Class: LD
  • Brand: PTI
