Part Story

Dsp Splined Sleeves

Part Number 3183-1601

  • Series: CVJ
  • Material: Steel
  • Spline Count: 16
  • Spline Diameter: 1.375
  • Tube Diameter: 2.500
  • Tube Wall: 0.083
  • Butt Diameter: 2.344
  • End To Weld: 12.5
  • Use With: P2-28-367, 3102-37
  • Notes: For JK Jeep front shaft with 100mm 8 bolt CVJ
  • Vehicle Class: LD
  • Brand: PTI
Part Story

Jeep JK Wrangler front shaft in 2.5" tubing. Uses standard 1310 weld yoke with 3102-37 or and upgraded 1350 yoke with 3502-37. Can be upgrade to 1350 shaft using 3501-321 companion flange. Kits will use 1350 double cardan (3590-2025) for 25-095 tubing.
