Part Story
Dsp Splined Stub Shafts
Part Number 1353-231
- Tube Diameter: 2.560
- Tube Wall: 0.065
- Butt Diameter: 2.435
- Spline Count: 23
- Spline Diameter: 0.990
- Spline Length: 1.375
- End To Weld: 5.000
- Style: Fixed
- Use With: 1301-231
- Midship: Yes
- Bearing Diameter: 1.181
- Notes: Fits Toyota OE Tube 65mm / 1374-233 nut included
- Vehicle Class: LD
- Brand: PTI
Part Story
This Toyota spline stub can be used with the 1301-231 companion flange.
