Dsp Splined Stub Shafts

Part Number 1253-262M

  • Tube Diameter: 2.000
  • Tube Wall: 0.095
  • Butt Diameter: 1.812
  • Spline Count: 26
  • Spline Diameter: 1.115
  • Spline Length: 1.180
  • End To Weld: 2.875
  • Style: Fixed
  • Use With: 1204-261
  • Midship: Yes
  • Bearing Diameter: 1.181
  • Notes: Uses 858018 nut, machine from 1253-262 for 2-095 tubing
  • Vehicle Class: LD
  • Brand: PTI
