Part Story

Dsp End Yokes

Part Number 4104-04

  • Series: 1410
  • Spline Count: 30
  • Spline Diameter: 1.590
  • Hub Diameter: 2.370
  • Thru Hole: 1.630
  • Centerline To End: 3.750
  • Style: BS
  • Diff Model: GM 10.5
  • Notes: Requires strap kit 3570-20,Includes new pinion seal (14 bolt GM)
  • Vehicle Class: LD
  • Brand: AAM
Part Story

This 1410 pinion yoke fits the GM 10.5" and 11.5" differentials. It takes the Dana strap kit 3570-20.

Applications for the GM 10.5"

1 Ton GM Pickup: 1973 - 2006 (Rear)
1 Ton GM Van: 1973 - 2004 (Rear)
3/4 Ton GM Pickup: 1973 - 2006 (Rear)
3/4 Ton GM Van: 1973 - 2006 (Rear)

Applications for the GM 11.5"

1 Ton GM Pickup: 2000 - 2006 (Rear)
3/4 Ton GM Pickup: 2000 - 2006 (Rear)
