Part Story

Dsp Splined Stub Shafts

Part Number 3140-1701-3

  • Tube Diameter: 1.250
  • Tube Wall: 0.120
  • Butt Diameter: 1.000
  • Spline Count: 16
  • Spline Diameter: 1.375
  • Spline Length: 6.500
  • End To Weld: 7.750
  • Style: Slip
  • Use With: Slip Yoke
  • Midship: No
  • Notes: Full Spline
  • Vehicle Class: LD
  • Brand: PTI
Part Story

This is a full spline stub with dust cap. Four wheel drive customers like this stub because of the long splines extra travel.
